"Unity"
Cold Water Pump controller is manufactured
in accordance to be standard and local requirements |
The
pump controller can be operated in automatic
coincidence detection or manual using push
button. |
| |
Booster
Pump, Transfer Pump, High Pressure Pump,
Pneumatic Pump and Submersible Pump |
The
panel come in various of range from 1 HP
to 7.5 HP using 415 V 3 PHASE, 50HZ. There
is two types of electrical starter available
for this controller, either star-delta starter
or direct on line starter depending on the
horsepower use. The standard panel is builded
for wall mounted type, indoor use only and
controller for 2 electrical pump. For special
requirement, the panel can also be available
above 7.5 HP, using 1 electrical and 1 diesel
engine pump or in weatherproof type (outdoor). |
| |
| Construction |
Standard
1.5 mm thick mild steel plate, coated with
"beige colour" epoxy paint. |
| |
| Standard
Features and Indications |
Phase
light indicator
Pump run and trip indicator
Manual start and stop push button
Incoming isolator or MCB for power supply
Individual MCB/ MCCB or each pump
Individual MCB for each pump controller
Auto/ Off/ Manual selector switch
Voltmeter & ammeter C/W selector switch
for power supply
Hour run meter (no available for High Pressure
Pump)
Low level indicator for suction tank (Booster,
Transfer, High Pressure Pump)
High level indicator for elevated tank (Booster/
Transfer Pump)
Overflow indicator and reset button (Submersible
Pump)
Alarm bell or revolving light output (Submersible
Pump)
Automatic changeover from pump 1 to pump
2 using latching relay or Time switch (expect
High Pressure Pump) |
| |
Certified
and approved by: Jabatan Bekalan
Elektrik Dan Gas TKL (PS) 79/98 |
| |
|
| |
Booster
Pump Controller |
| |
| |
Booster
Pump Controller for 2 System
(4 Electrical Pump) |
| |
|
High
Pressure Pump Controller |
| |
|
Submersible
Pump Controller |
| |
|
Submersible
Pump Controller (Weatherproof) |
|
